This repository provides Unitree G1 deployment code for GRIT v0.0.1, a whole-body motion-tracking control algorithm for humanoid robots. The policy inference process communicates through a unified UDP interface, enabling the robot to track an operator's full-body motion using PICO.

This repository includes:

• the GRIT ONNX policy and its deployment contract
• a 50 Hz Python inference and control runtime
• headless and interactive MuJoCo sim2sim
• PICO/XRoboToolkit live-motion retargeting
• a native Unitree SDK2 hardware bridge with a stale-command watchdog

Training and data-generation code are outside the scope of this repository.

.
├── sim2real/
│   ├── checkpoints/                 # GRIT ONNX model and runtime contract
│   ├── config/g1/
│   │   ├── motions/                 # example reference motions
│   │   ├── tracking.yaml            # local reference-motion mode
│   │   ├── tracking_vr.yaml         # live PICO mode
│   │   ├── controller.yaml          # policy loop, gains, and joint order
│   │   ├── bridge.yaml              # MuJoCo UDP bridge settings
│   │   └── retarget/teleop.yaml     # PICO retargeting and browser-viewer settings
│   ├── src/
│   │   ├── deploy.py                # GRIT inference and control entry point
│   │   ├── sim2sim.py               # MuJoCo robot process
│   │   └── runtime/
│   │       ├── grit_policy.py       # GRIT ONNX/action contract
│   │       └── grit_observation.py  # GRIT observation construction
│   ├── teleop/                      # XR stream, G1 retargeting, and port-8080 viewer
│   └── tests/test_grit_contract.py
├── g1_sim2real/                     # native Unitree SDK2 bridge
└── THIRD_PARTY.md

• Ubuntu 22.04 or 24.04 on x86_64 or aarch64
• Python 3.10 and uv
• CMake 3.16+, a C++17 compiler, make, and flock
• a working MuJoCo graphics stack for the interactive simulator
• XRoboToolkit, its Python SDK, and low-latency Wi-Fi shared with the workstation for PICO control
• a Unitree G1 and a dedicated robot-facing network interface for hardware use

Install the Python environment from the repository root:

cd sim2real
uv sync
cd ..

Run the simulator in terminal 1:

cd sim2real
uv run src/sim2sim.py --robot g1

Run GRIT in terminal 2:

cd sim2real
uv run src/deploy.py \
  --robot g1 \
  --tracking-config tracking.yaml \
  --policy-path checkpoints/policy.onnx

Press s in the GRIT terminal (terminal 2) to enter the controlled default standing pose. The tracking policy is active and holding this pose immediately after the transition. Then press a there to start the NPZ trajectory from its first frame. Press x in the simulator terminal to stop the simulation.

tracking.yaml plays config/g1/motions/walk_turn.npz once by default. Override it with another GRIT-compatible reference:

cd sim2real
uv run src/deploy.py \
  --robot g1 \
  --motion-file /path/to/reference.npz \
  --policy-path checkpoints/policy.onnx

After one complete playback, GRIT automatically returns to and holds the default pose. Pose transitions use transition_steps. The simulator terminal has its own x key, which stops MuJoCo rather than the GRIT process.

If you have not configured the PICO software, follow this guide first: PICO hardware, XRoboToolkit, calibration, and network setup guide

Install the XRoboToolkit PC service at /opt/apps/roboticsservice, then install its Python binding into the GRIT environment:

cd sim2real
bash install_xrobottoolkit_sdk.sh

The Python binding is installed separately from the packages managed by uv. After installing it, use uv sync --inexact for later environment syncs so the binding is retained.

This repository supports PICO teleoperation over Wi-Fi only. Start the XRoboToolkit PC Service:

bash /opt/apps/roboticsservice/runService.sh

Find the workstation's Wi-Fi IPv4 address and enter it as PC Service in the XRoboToolkit headset client. Do not use 127.0.0.1, a container address, or the dedicated G1 network-interface address. The headset must display WORKING, with Head, Controller, Send, and Full body enabled.

Start the retargeting process with:

cd sim2real
taskset -c 1 uv run teleop/serve_xrobot_teleop.py --robot g1

The retargeting process also starts the browser viewer by default. Open http://localhost:8080 on the workstation to inspect the human pose and the retargeted G1. Other devices on the same LAN can use http://<workstation-wifi-ip>:8080.

The live control pipeline uses TCP ports 28701, 28702, and 28703; the browser viewer uses TCP port 8080.

If the listed CPU IDs are unavailable on the workstation, omit the taskset -c ... prefix. CPU affinity is an optimization, not a functional requirement.

Start the following processes in order:

# terminal 1: PICO retargeting
cd sim2real
taskset -c 1 uv run teleop/serve_xrobot_teleop.py --robot g1

# terminal 2: MuJoCo
cd sim2real
uv run src/sim2sim.py --robot g1

# terminal 3: GRIT control
cd sim2real
taskset -c 4-7 uv run src/deploy.py \
  --robot g1 \
  --tracking-config tracking_vr.yaml \
  --policy-path checkpoints/policy.onnx

Press s in terminal 3 before activating live control.

G1 hardware supports two separate workflows: local NPZ playback and PICO live control. Do not mix their tracking configurations or startup sequences.

Before either workflow:

• validate the exact model, configuration, and NPZ/PICO input in MuJoCo;
• secure or suspend the robot for initial runs and keep physical support until the default pose and first motion have been verified;
• maintain a clear radius of at least 3 m around the robot, with no people, obstacles, loose cables, steps, or fragile equipment inside that area;
• keep a trained operator at the physical emergency stop, positioned outside the expected motion path, and do not rely on keyboard or software stop logic;
• verify the joint order, gains, default pose, network interface, model hash, battery state, and available floor traction before enabling control.

Build the native bridge once:

cd g1_sim2real
bash scripts/build.sh
cd ..

Replace enp129s0 in the commands below with the workstation interface connected to the G1. If a listed CPU ID is unavailable, omit the corresponding taskset prefix.

Validate the exact NPZ in MuJoCo first. Then start the native bridge in terminal 1:

cd g1_sim2real
G1_NET=enp129s0 taskset -c 2-3 bash scripts/run_bridge.sh

Start GRIT local NPZ control in terminal 2:

cd sim2real
taskset -c 4-7 uv run src/deploy.py \
  --robot g1 \
  --tracking-config tracking.yaml \
  --motion-file config/g1/motions/walk_turn.npz \
  --policy-path checkpoints/policy.onnx

Only after GRIT reports valid robot state, press s in terminal 2 to enter the controlled default pose. Keep the robot physically supported during this transition. While the default pose is held, the reference heading follows the measured pelvis yaw, so the operator can reposition and reorient the supported robot. Press a to capture the latest heading and play the NPZ from frame 0.

After the NPZ completes, GRIT automatically returns to the adjustable default pose. After stopping GRIT with x, press q in terminal 1 to stop the native bridge and its low-level loop.

Start the following three processes after completing the PICO setup and MuJoCo validation:

# terminal 1: PICO retargeting
cd sim2real
taskset -c 1 uv run teleop/serve_xrobot_teleop.py --robot g1

# terminal 2: Unitree bridge
cd g1_sim2real
G1_NET=enp129s0 taskset -c 2-3 bash scripts/run_bridge.sh

# terminal 3: GRIT control
cd sim2real
taskset -c 4-7 uv run src/deploy.py \
  --robot g1 \
  --tracking-config tracking_vr.yaml \
  --policy-path checkpoints/policy.onnx

Press s in terminal 3 only after GRIT reports valid robot state. Then use the PICO controls documented above. Keep the 3 m clear radius and physical emergency stop available throughout operation.

Press x in terminal 3 to enter damping mode and exit GRIT control. Press q in terminal 3 to emergency-exit the GRIT control process, or in terminal 2 to emergency-exit the native bridge and its low-level control loop. The bridge also accepts q while it is still waiting for its first DDS LowState, so a disconnected or misconfigured robot interface does not trap the process during startup. This keyboard action is separate from the PICO controls and does not replace the robot's physical emergency stop.

The native bridge keeps Unitree's motion service active until it receives a valid Python command. After handoff, a stale or missing command stream switches the watchdog to a log-only timeout state after 0.2 s by default. It does not write damping or otherwise modify the current low-level command while waiting for the Python command stream to recover. This watchdog is not a substitute for a physical emergency stop or a tested recovery procedure.

The bundled files are:

sim2real/checkpoints/policy.onnx
sim2real/checkpoints/policy.json

The ONNX graph must expose this exact interface:

The runtime rejects incompatible input or output names. See sim2real/checkpoints/README.md for checksums and replacement guidance.

Reference NPZ files use the GRIT motion contract: fps, joint_pos, joint_vel, body_pos_w, body_quat_w, body_lin_vel_w, and body_ang_vel_w.

Run the GRIT deployment contract tests:

cd sim2real
uv run python tests/test_grit_contract.py -q

Build-check the native bridge:

cd g1_sim2real
bash scripts/build.sh

The model in this release is a beta trained on only 10+ hours of open-source data. It can track most reference trajectories, but we recommend operating the robot with an overhead safety rig and exercising extreme caution.

Parts of this deployment implementation were developed with reference to and adapted from the sim2real branch of Axellwppr/motion_tracking. The upstream project is Copyright (c) 2026 Axell and is distributed under the MIT License. We thank the original author and contributors for making their implementation publicly available.
